Viper Pro Series II 1500 Electric Anchor Winch Bundle – Includes 200m Rope Kit
The Viper Pro Series II 1500 is the most powerful anchor winch in the Viper range, specifically designed for larger vessels 8 meters and above. With an incredible rope capacity of 200 meters of 6mm double braid rope, spliced to 10 meters of 8mm short link chain, anchoring in deep water has never been easier. The 1500 is capable of hauling a 37lb+ anchor all day, combining speed, power, and reliability.
This fastest drum winch in the Viper range boasts an amazing fall rate of 55 meters per minute, making deployment and retrieval quicker than ever. For installation, simply add your own cabling or one of Bell Marine’s custom tinned copper marine wiring looms. The motor comes with 1 meter of 3 B&S cable pre-attached for ease of installation (3-cable setup)
Built for Reliability and Performance:
-
More torque than conventional drum winches
-
3 support bearings hugging a 1-piece 32mm solid stainless steel shaft
-
90° welded housing bracket closes the gap between drum and rope to prevent jams
-
Constructed from 8mm plate 316 marine-grade stainless steel
-
Hand-polished mirror finish
-
No additional guards required
-
5-year Viper performance warranty
What’s Included in the Bundle:
-
30003-S Viper Pro Series II 1500W Anchor Winch
-
30027 200m of 6mm double braid premium rope spliced to 10m of 8mm chain
-
30019 Large Viper Pro Series Anchor Swivel
-
30002 Large Viper Deluxe Anchor Roller
-
30024 400A Reversing Solenoid
-
90021 LED Illuminated Marine Rocker Switch
-
90046 Viper Laser-Etched LED Switch Cover
-
30025 135A Flush Mount Circuit Breaker with Rubber Seal
-
30051 Single LED Switch Stainless Steel Faceplate
-
30052 Combo LED Switch & Circuit Breaker Stainless Steel Faceplate
