GBS Super Bolt Clamps W4 – 304 Stainless Steel (Heavy Duty)
Designed for high-performance and demanding applications, GBS Super Bolt Clamps deliver superior clamping force and reliability. Manufactured from AISI 304 stainless steel (W4 – all parts stainless), these heavy-duty clamps are ideal for marine, automotive, agricultural, and industrial use.
Engineered for strength, these clamps offer significantly improved performance, with failure torque doubled and band tensile force increased by up to three times, ensuring a secure and long-lasting hold even in extreme conditions.
Key Features:
-
W4 All Stainless Steel (AISI 304) – excellent corrosion resistance
-
Heavy-Duty Design – built for high-pressure and demanding applications
-
High Clamping – improved torque and tensile strength performance
-
Wide Adjustment Range – suits a large variety of hose diameters
-
Reliable & Durable – ideal for marine, industrial, automotive, and agricultural use
Applications:
-
Marine exhaust and cooling systems
-
Industrial hose connections
-
Agricultural machinery
-
Automotive heavy-duty hose systems
Technical Specifications:
| Part No. | Clamping Range (mm) | Band Width (mm) |
|---|---|---|
| NGBS18 | 17–19 | 18 |
| NGBS22 | 21–23 | 18 |
| NGBS28 | 27–29 | 18 |
| NGBS30 | 29–31 | 18 |
| NGBS33 | 31–34 | 18 |
| NGBS36 | 34–37 | 18 |
| NGBS39 | 37–40 | 18 |
| NGBS42 | 40–43 | 18 |
| NGBS45 | 43–47 | 20 |
| NGBS49 | 47–51 | 20 |
| NGBS53 | 51–55 | 20 |
| NGBS57 | 55–59 | 20 |
| NGBS61 | 59–63 | 20 |
| NGBS66 | 63–68 | 20 |
| NGBS71 | 68–73 | 25 |
| NGBS76 | 73–79 | 25 |
| NGBS82 | 79–85 | 25 |
| NGBS88 | 85–91 | 25 |
| NGBS108 | 104–112 | 25 |
| NGBS117 | 112–121 | 25 |
