Muir AA150 Control and Counter – Auto Anchor System
The Muir AA150 Control and Counter simplifies the anchoring process, allowing boat operators to drop or retrieve the anchor with minimal effort. Designed for precision, convenience, and safety, this panel-mounted system gives you full control over anchor deployment and monitoring.
Key Features:
-
Precision Control: Accurately set anchor depth and scope for secure mooring.
-
Rode Length Monitoring: Large LCD display with adjustable red backlighting shows rode deployed in feet or meters.
-
Safety Features: Includes docking alarms, overload protection, and emergency stop options.
-
Pre-Programmed Calibrations: Compatible with rope or chain rodes.
-
Multi-Station Capability: Install up to two units or combine with AA550RC, AA500C, or AA601 for multiple control stations.
-
Standard Marine Gauge Size: 60mm (2.36") diameter console fits standard marine instrument panels.
Technical Specifications:
-
Power Supply: 12/24V DC
-
Temperature Range: -5° to 60°C (23° to 140°F)
-
Current Consumption: 30mA
-
Maximum Voltage: 30V
-
EMC/Protection/CE: EN60945
-
Solenoids: N/A
-
Dimensions: Diameter 60mm (2.36")
Package Inclusions:
-
1 Console unit
-
1 Sensor with 2m cable
-
1 Magnet
-
Load sensing connectors
-
Installation and operation instructions
Applications:
-
Anchor monitoring and deployment for leisure and commercial vessels
-
Docking and mooring safety systems
-
Multi-station marine control setups
