Cast Stainless Steel Bolt-Through Heavy Duty Cleats
Premium mirror-polished cast 316-grade stainless steel cleats designed for larger yachts and cruisers. The bolt-through mounting system fastens from underneath the cleat, maintaining a sleek deck finish while providing a strong, secure installation.
The raked design accommodates large mooring ropes and can also function as a fairlead or stern chock. Each cleat is supplied with two stainless steel all-thread bolts, nyloc nuts and washers.
Key Features
-
Heavy-duty design for larger vessels
-
Raked profile accommodates large ropes
-
Can also be used as a fairlead or stern chock
-
Underneath bolt-through mounting for streamlined styling
-
Supplied with stainless steel mounting hardware
-
American Boat & Yacht Council (ABYC) approval
Specifications
-
Material: Cast 316-grade stainless steel
-
Finish: Mirror polished
-
Mounting: Bolt-through from underneath
-
Maximum deck thickness with supplied hardware: 40mm
-
Longer all-thread bolts can be used for thicker decks
Available Sizes
RWB1282 – 200mm Cleat
-
Total length: 200mm
-
Base: 145 × 35mm
-
Bolt size: 60 × 10mm
-
Suitable for boats up to 35ft
RWB1283 – 250mm Cleat
-
Total length: 250mm
-
Base: 177 × 43mm
-
Bolt size: 60 × 10mm
-
Suitable for boats up to 40ft
RWB1284 – 300mm Cleat
-
Total length: 300mm
-
Base: 213 × 50mm
-
Bolt size: 65 × 12mm
-
Suitable for boats up to 50ft
