Description
Glomex 'Nashira AGC' 370mm TV Antenna
Nashira evolves in Nashira AGC to make your life easier and more comfortable with the new and innovative automatic gain control amplifier.
Thanks to the new amplifier you have only to turn on the TV, stay comfortably seated on the sofa and enjoy your favourite programs;
Nashira AGC will adjust by itself the gain of the TV signal to ensure the best possible reception of television broadcasts.
Conventional amplifiers you have to manually adjust the TV signal gain by lowering the amplification when the signal is high and by increasing the amplification when the boat is at sea and far from the TV transmitter. The new Nashira AGC, everything will happen automatically and the innovative amplifier can be placed in a hidden location inside the boat.
- Essential style
- Aerodynamic lines with the “shark fin” (55mm/2.2” high) for receiving the vertically polarized TV signals
- Reinforced base to ensure maximum stability of the antenna in any condition of navigation
- Compact size (370mm/14” diameter)
- High quality construction materials.
If matched with a 2-way splitter installed between the antenna and the amplifier, it can also receive AM-FM radio frequencies.
Supplied with:
- Automatic Gain Control Amplifier
- 20m Coaxial cable to connect the antenna to the amplifier
- 1.5m SED cord to connect the amplifier to the TV/Decoder
- Female gold plated connector
|
ANTENNA DIAMETER |
370 mm (14'') |
| ANTENNA HEIGHT | 185 mm (7'') [240 mm (9.5") with shark fin] |
| BASE DIAMETER | 25 mm (16'') |
| ANTENNA WEIGHT | 900 g (31,74 oz) [975 g (34,39 oz) with shark fin] |
| RADOME MATERIAL | U.V. resistant ASA |
| ANGLE OF RECEPTION |
360° |
| POLARIZATION | Horizontal / Vertical |
| IMPEDANCE | 75 ohms |
| FREQUENCY RANGE | 40/890 MHz |
| GAIN AVERAGE | 27,5 dB |
| NOISE FACTOR | 2,1 dB |
| POWER CONSUPTION | 20 mA |
| POWER SUPPLY | 12/24 Vdc |
| ANTENNA AMPL/BY PASS | Yes |
| ADJUSTABLE GAIN | Yes |
| TV SET MAX | 2 |
| TERMINATION | F female |
| CONNECTOR SUPPLIED | F male gold plated connector (V9144) |
| A/B SWITCH | No |
